MAE’s Chassis Dynamometers reproduce road conditions under the most demanding environmental conditions.
Mileage Accumulation requires extreme durability from a Chassis Dynamometer and related testing components. Many times mileage accumulation is performed in a limited covered outdoor environment which produces a harsh environment for the equipment. MAE has designed our world class Chassis Dynamometers and support equipment to exceed the perform requirements under these demanding conditions while having the durability to last for many years of mileage accumulation testing.
Mileage Accumulation Literature – PDF files
- Safe, experienced vehicle testing
- Supported by the validation testing on the only private autonomous test track in the USA
- 50” All-wheel drive or two wheel drive dynamometers with the capabilities of testing up to 250 MPH and 12,000 lbs axle weight
- Robot/automatic actuators drive the vehicles for 24/7 automatic testing
- SAE 1634 for EV and full CFR 1066 compliance for vehicle evaporative emissions
- SAEJ2264 Compliant
- AWD dynamometer has light duty transient drive cycle capabilities including: WLTP, FTP 75 (Light Duty), EPA US06 Supplemental FTP Driving Schedule (Light Duty), SC03 Test Cycle
Vehicle Sizes:
- ATV, Motorcycle, Scooters, Golf Carts, Snowmobile
- Auto Passenger Vehicles < 10,000 lb. / 4,545 Kg
- Auto Passenger Vehicles / Light Truck < 14,000 lb. / 6,400 Kg
- Truck < 80,000 lb. / 36,400 Kg
- Extreme Truck
Standard EEC Chassis Dynamometer Performance Specifications:
- Roll Configuration: Single Roll, 2×2, 4×4, 6×6, 8×8, 10×10
- Motor Configuration: Independent Motor/roll, Motor Inline (MIL)
- Available Roll Diameter: 20″, 48″, 72″ (508, 1,219, 1,905 mm)
- Speed: up to 120 mph (200 km/hr)
- Power Range per Axle: 50 to 800 Hp (37 to 600 kW)
EEC Chassis Dynamometer Extras:
- Piped Motor Cooling Air
- Liquid Cooled Motors
- Stainless Steel Floor Plates
- Insulated Floor Plates
- Roll Isolation Environment Enclosure
- Torque Measurement Environmental Control Enclosure
- Automatic Transmission Driver Control System (Throttle, Brake, Ignition, with or without Gear Shift)
- Manual Transmission Driver Control System (Throttle, Brake, Clutch, Ignition, Gear Shift)
- Truck 5th Wheel Trailer Load Simulator
- Restraint System
- Variable Speed Vehicle Frontal Cooling Blower and/or Dual Side Cooling Blowers (not for use in wind tunnel)
When the testing climate is controlled, in a nominal temperature range of 5°C to 40°C MAE’s standard durability Chassis Dynamometer can be supplied. MAE’s durability dynamometers are designed for 24/7/365 continuous use and designed with components that can handle this continuous many over sized components such as roll bearings, top plating structure, tie downs, motor cooling, etc.
Contact MAE for your Mileage Accumulation Chassis Dynamometer requirements by calling 330-963-5400. Email us at sales@mustangae.com.
